SQ813x Macan
Flagship Post-Quantum Secure Element
SQ813x is a flagship post-quantum secure element integrating a native PQC engine, a high-order enterprise crypto engine, and a comprehensive anti-tamper enclave. Driven by a RISC-V core, it delivers quantum-safe protection for Physical AI and enterprise servers.
Certifications
NIST CMVP (FIPS 140-3) Cryptographic Module Validation Program (in progress)
Security Assets
Hardware-Accelerated Post-Quantum Cryptography (PQC)
Native hardware engines for NIST FIPS 203 (ML-KEM) and FIPS 204 (ML-DSA) lattice-based algorithms, ensuring long-term immunity against quantum computer decryption and CNSA 2.0 compliance.
Comprehensive Anti-Tamper Enclave
Matches SQ719x's top-tier physical defense with a full-coverage active top-layer metal shield, independent internal clock, SPA/DPA side-channel defense, and sub-microsecond (<1 µs) automatic key zeroization for physical AI and Edge AI servers.
High-Order Enterprise Cryptography Suite
Extends general cryptographic capabilities with high-order asymmetric curves ECC up to P-521, RSA up to 4096-bit, full SHA-2/SHA-3 family, and Poly1305, to protect enterprise systems.
API Integration
Driven by a 32-bits RISC-V high-performance processor with rich interfaces (USB 2.0 High Speed, QSPI x2, CAN 2.0B) and comprehensive software stack (iMQ SE API, TPM 2.0 API, Java Card, eSIM, and PQC FIDO2).
Environmental Specs
With an operating voltage range of 1.62 V to 3.63 V and an industrial-grade operating temperature range of −40°C to 105°C, SQ813x Macan meets the most stringent operational demands of industrial electronics and high-performance Edge AI systems.
Target Applications
Enterprise Authentication:
FIDO2 security key cards and enterprise access control systems.
Edge AI / Physical AI / Humanoid Robotics:
Secures high-performance AI devices, AI servers, humanoid robots, and edge AI Agents with secure firmware boot, IP model protection, and post-quantum defense.
