SQ7191, SQ7193

Brief

SQ7191, SQ7193 is the PUF-Based Secure Element. PUF exploits the silicon’s inherent physical variations to generate cryptographic keys on demand—keys that are never stored and cannot be duplicated. This PUF-driven approach creates an immutable hardware “root of trust,” inherently resilient to cloning, extraction, and invasive attacks. The PUF demonstrates strong randomness with a 50% Hamming Weight, uniqueness with a normalized Hamming Distance centered at 0.5, and proven reliability test results. The device supports symmetric/asymmetric authentication, attestation, and TLS1.2 and 1.3 secure connection. It is embedded high quality TRNG(True Random Number Generator), hardware asymmetric/symmetric algorithms: ECC-256, AES-128/AES-256, and SHA-256. Using the active tamper detection & side channel countermeasure technology to raise up system's security level. In addtion, the device supports a wide operating range from 2.5 to 5.5V. It is easy to integrate to original design with standard I2C(SQ7191)/SPI(SQ7193) interface. This Secure PUF ASIC is suitable for IoT device signature & verification, smart home appliances, system anti-cloning, secure boot/secure OTA, end-to-end encryption, etc.

Features

• 128-bit Unique ID (UID) + 256-bit PUF Unique ID (PUID)
• Asymmetric and Symmetric Authentication & Attestation for IoT Application
  • Asymmetric Sign and Verify :ECDSA
    • Support X.509 Certificate
    • Support TLS 1.2, 1.3 Cloud Connection
    • Compliant to WPC(Wireless Power Consortium) Qi v1.3 Security Standard
  • Key Agreement: ECDH
  • Symmetric Crypto Algorithm
    • AES-128/AES-256,SHA-256
  • True Random Number Generator(TRNG)
  • PRF/HKDF Calculation for TLS 1.2 & 1.3
• NIST CAVP Certified Cryptographic Algorithms
  • DRBG/AES/SHA-2-256/HMAC/ECDSA
• NIST ESV Certified and CMVP FIPS 140-3 Complied
• SESIP & PSA Level 3 certification ready
• High Level Secure Storage
  • Keys(ECC-256 & AES-256/128)
  • X.509 Compressed Certificate
  • Large User Data : 5.6KB
• Active Tamper Detection & Side Channel Attack Countermeasures
• Support Secure Boot & Secure OTA
• Matter for SmartHome
• System Anti-Cloning
• End-to-End Encryption

Products and Package Type

Datasheet

• English - iMQ SQ7191 7193 Brief Datasheet V1.0.pdf

Development Tools

• Secure Starter Kit
